FAQ Q&A
Frequently Asked Questions
Our Smart-BUS Protocol is Global and Fully Open Protocol.
We have also Provided Open Source, PCB Designs, Simulators and DLL.
Smart-BUS is approved and Pushed by Many Governments and Universities as well as Engineering Societies Including: India, Nigeria, Iran, Kuwait, Vietnam and South Africa.
We are more than happy to Give you all Needed Protocol Document for your Educational Needs. Please, let us know if you require Any Equipment or other Training and Testing Devices to Train Your Students Officially.
Here is the link of our protocols smarthomebus.com/downloads-7-protocols.html
Dear Sir,
Congratulations first of all on your New Business, we wish you the good out of this new venture, and we hope this would land you with a happy team and exciting work/career.
In answer to your Points:
- Yes Dealer is a free man and can offer what he or his client requires.
- Regarding Price, We sell to everyone same cost, it is after that up to them to add margins based on:
- Their Work Load
- Their Level of Expertise
- The Project Headache
- Project Distance and Support Need During Construction then after
- Client’s Demand Complexity
- Client’s Budget and Relationship Level
- Their Profit Margins
- The Ideas and Level of Integration that will be done
- Expected Length of Project Execution
- Payment Terms and Cash Flow
- Project Reference and Reputation
- Supply and Demand in that Area
- Competition and Awareness
- And Many More … etc.
- No one can handle all jobs, all awareness education, all support and branding, etc. Our Policy is an Open Policy, we never forbid anyone from trying his best. At the end, authority is taken not given, and every one will position himself in market as it is in life today.
- At the End, it is not what I want or you want. GOD is the only Giver, and client is the one that decides based on his trust, his budget and his comfort. (So have faith, do your Job Always perfect, wait for no one and waste no time, then leave it to GOD. GOD knows the Hidden and what is better for you).
Now to keep things short, I advise not to think allot.. Just Do it, Results will come.
Thank you,
Firas Khalid Mazloum
ceo, Smart Industry Group
.
Yes, you are able to deal with Smart-Group directly without a middle-man or a company. Kindly contact us for direct liasing.
Did you know?
- Smart-Group policy is an open policy. Any installer can get a dealership, free training and certification. Additionally, any installer can buy directly from the factory at best prices.
- Smart-Group policy guarantees open protocol, globally. Any integrator, app developer, manufacturer, and alike, has full access to all products, including general communication protocols, simulators, and more.
- Smart-Group policy believes in open source, shared designs, and experience. (Knowledge to all)
- Smart-Group believes in an open door policy. You may directly contact the CEO of Smart-Group at any time and any day. The contacts of the CEO of Smart-Group can be found online.
- Smart-Group believes that SmartHome is for everyone. Smart-Group believes in delivering cutting edge technology at affordable prices. Thus, Smart-Group maintains a best-price policy always.
30,000 HVAC2 modules can be connected.
250,000 addressable Zones can be connected and monitored.
16.5 Million Devices or modules can be connected.
No, no need for end of line terminators. (For any example is the same answer)
Yes, sure you can program manually any (G4) Smart-BUS lighting module like Dimmers and Relays and pair the channel to any DDP or soft Button Panel switches. Once pairing is done, all characteristics of the module will also be active like: on/off/dim/ramp.
- Manually also can program the following:
- LED Color
- Motors Control
- HVAC
- Music
- Moods
- Scenes
- PIR
- and many More
Yes, sure. DDP can Pair direct to all the following: Dimmer, relay, Z-Audio2, HVAC2. And once pairing happen then all characteristics and functions are automatically activated like: on/off/temp/fanspeed/mode/songs/playlist/volume/play/stop/FW/BW...Etc.
Yes, we are almost finished from this function, and it is being tested. Currently we are putting the default “ON” time as 7 minutes before circuit energy save if no motion is detected.
Here is the connection diagram with the configuration settings of each devices:
- 1. First you have to put your songs in Folders like this :
- D:\Main folder\FOLDER 1
- D:\Main folder\FOLDER 2
- D:\Main folder\FOLDER 3
- D:\Main folder\FOLDER 4
- D:\Main folder\FOLDER 5
- Choose any name, put your folders inside the main folder then put your songs in these subfolders (FORLDER1, FOLDER2 . . . )
- 2. Make sure the format is MP3
- 3. Download the Last update of FTP server http://downstairs.dnsalias.net/files/HomeFtpServerInstall.exe
- 4. Upgrade your Z-audio And DDP to last Firmware.
http://www.youtube.com/watch?v=Pc4O6mvyjcs&feature=plcp
Watch here http://www.youtube.com/watch?v=JmMvtmlN15E&feature=plcp
A: For the Relay, it is a pass through device, meaning what ever is in, it is out. So yes, it will do for both AC and DC. For the Dimmer, it has a dimming ability from 0 to 100%, so it is preferably if you connect to it only a dimmable load.
We designed them like that. DDP has 7 pages in total, 3 of them are fixed page(Music,AC,floor heating), 4 of them are dynamic page ( from 1 to 4). The default page is page 1, press left button it will go to Music, press right button it will go to AC, Since there 3 page are most often to use.
Connect RSIP with LAN & S-BUS both,
Connect Z-Audio only with LAN but without S-BUS
Set the IP address of your router and computer to be 192.168.1.*，then can link to rs232ip.After connected,you can modify RS232IP address whatever you like.
Our Smart-BUS Protocol is Global and Fully Open Protocol. It is approved and Pushed by Many Governments Including India, Nigeria, Israel, and South Africa. We are more than happy to Give you all Protocol Document for your Educational Needs. Let me know if you Require also Any Equipment or other Training and Testing Devices to Train Your Students Officially. Here is the link of our protocols http://smarthomebus.com/downloads-7-protocols.html
No, 3R can not create a sequence. 4ch, 6ch, 8ch and 12ch can do this.
You should use hotel SW to control bedside controller but not Smart Cloud. Kindly download from Drive
The Simple S-BUS PIR It is to be used as Normal PIR but the advantages are:
- No Need to install Separate Powersupply (Powers from BUS)
- No Need to Add 4-Z as it is BUS Ready
- It has 5Volt Trigger Output that you can connect to Auxiliary 5V Relay contactor for Additional needs
Here is the command for activating macro:
single channel command
first PARA:macro no (from 1-20)
second PARA: run macro=100, stop macro=0
third PARA: delay time(0s-10hours)
Trail Click is a small module like 4z in size that click behind ddps. And can also be clicked on to it in train effect like sandwich so all retro components look and acts as one mix module.
https://drive.google.com/drive/folders/1GsD0r3oKXi_aT5m1X9JUMCHcKvrf8BE6
https://drive.google.com/drive/folders/1U9znLFms6eQ2Quom_im5eKvqs7_wQLzt
Since Most of the Automation industry Dealers are installers and deal with End Users.
Accordingly, the dealer/Installer is not B2B.
Execlusivity is Given to companies in small areas or to companies that are ready to act as stockiest for big areas/countries
For execlusivity must establish also Training Center, Support Center, and Keep large stock that must be renewed quarterly.
Yes we allow OEM/ODM for big orders There is 3 Levels of such:
- Simple (only add logos, models, and give plain carton boxes)
- Pro (Customize the Cartons and the configuration SW
- Ultimate (Change the Plastic colors, change switch general icon feel, Customize Apps and More)
We have several technologies now:
- SmartBUS SBUS- Wired professional Luxury Technology
- KNX- Wired Pro technology
- Hybrid Retrofit wired Affordable luxury Technology
- Plug and Play Simple 220V Powercom Technology
- Wireless WiFi DIY Technology
- Wireless Zigbee DIY Technology
- We also supply Powerline and wireline outlets, Audio products, and Motorized solutions
Training is 4 levels but all require you to have equipment in advance, otherwise the training is not going to be useful:
- Train on your own, using manuals and videos online
- Train Online via webinars
- Train at nearest available dealer/distributor (this require coordination and fees)
- Come to get advanced training in China when you can (Free)
